Alpine MRX-F35 | 4 Channel Class D 650W Power Amplifier
Introducing the new ALPINE MRX-F35 digital X-Power series of Class-D amplifiers. The X-Power amplifiers incorporate many of Alpine’s PDX advanced digital technologies at an affordable price. Don’t let their small size fool you, these amplifiers were specifically engineered to offer performance, sound quality and reliability at PDX standards.
Features
• 4 Channel
• 4ch/3ch/2ch Configuration
• Class D
• Thermal Management Control
• DC-DC PWM Power Supply (Direct FET Power)
• Crossover Frequency:
- (HPF): 50 - 400 Hz, -12dB/oct
- (LPF): 50 - 400 Hz, -12dB/oct.
• Current Protection:
- Over-Current
- Over-Voltage
- Thermal Protection
Specifications
• Total Max Power: 650W
• RMS Power:
4ch Configuration:
4 x 55W (4Ω)
4 x 85W (2Ω)
3ch Configuration:
2 x 55W (4Ω) + 1 x 170W (4Ω)
2 x 85W (2Ω) + 1 x 170W (4Ω)
2ch Configuration:
2 x 170W (4Ω)
